Inlets
The inlets adapt to any kind of pool. The return inlets return filtered, treated water to the pool. They include the “Multiflow” system, which allows the diameter, and therefore the flow rate of the water through the inlets, to be selected.
- The suction inlets are used to connect the pool cleaner.
- The bottom inlets are placed in the floor of the pool, returning water at floor level. They prevent dirt from settling by carrying it towards the surface.
- Available for concrete and prefabricated pools. The versions for prefabricated pools include gaskets and screws for a perfect watertight seal.
ABS RETURN INLET FOR CONCRETE POOLS
Multiflow return inlet threated
MULTIFLOW SYSTEM.
Code | Description |
00295 | Return inlet Multiflow White |
00295CL090 | Threaded Multiflow return inlet – Beige |
00295CL129 | Threaded Multiflow return inlet – Light grey |
00295CL144 | Threaded Multiflow return inlet – Anthracite grey |
The eyeball has been marked with a series of “knock-outs” at 14, 20, and 25 mm, enabling the required flow to be selected at the time of installation.
Recommended max flow 4 m/sec., complies with EN 13451-1:
Ø 14 mm = >2.2 m3/h, Ø 20 mm = 4,5 m3/h, Ø 25 mm = 7 m3/h 2″ external thread, Ø 50 mm. Made in white ABS. Can be installed with wall conduits: 15658-15659. Grille slots are < 8 mm. Complies with EN 13451-1.
Complies with standards:
EN 16582-1
EN 16713-2
Download DATA SHEET
Multiflow return inlet to glue PN 6
MULTIFLOW SYSTEM.
Code | Description |
00298 | Return inlet Multiflow for gluing White |
00298CL090 | Multiflow return inlet to be glued – Beige |
00298CL129 | Multiflow return inlet to be glued – Light grey |
00298CL144 | Multiflow return inlet to be glued – Anthracite grey |
The eyeball has been marked with a series of “knock-outs” at 14, 20, and 25 mm, enabling the required flow to be selected at the time of installation.
Recommended max flow 4 m/sec., complies with EN 13451-1:
Ø 14= 2,2 m3/h, Ø20 = 4,5 m3/h, Ø25 = 7 m3/h. To glue onto Ø 63 mm, outside 6 bar pipe and inside Ø 50 mm. Made in white ABS. Can be installed with wall conduits: 15661-15660. Grille slots are < 8 mm. Complies with EN 13451-1.
Complies with standards:
EN 16582-1
EN 16713-2
Adjustable angled bottom inlets
Angled body in PVC. Lid in ABS.
Code | Description |
22353 | Adjustable angled bottom inlets Tube Ø75 mm White |
22353CL090 | INLET TILTING WITH GLUED PIPE (Ø75 mm) Beige |
22353CL129 | INLET TILTING WITH GLUED PIPE (Ø75 mm) Light Gray |
22353CL144 | INLET TILTING WITH GLUED PIPE (Ø75 mm) Anthracite |
Regulating screw in POM. Max. flow: 10000 l/h
Allows 8º adjustment.
Item available in White, Beige, Light Gray and Anthracite colours.
Complies with standards:
EN 16582-1
EN 16713-2
Download DATA SHEET
Multiflow return inlet to glue PN10
Multiflow return inlet to be glued to a Ø50 mm
Code | Description |
24413 | Multiflow return inlet 95×28 to glue inside D.50 mm PN10 pipe |
33428 | Multiflow return inlet to be glued in concrete pools |
33501 | Multiflow return inlet 88×24 to glue inside D.50 mm PN10 pipe |
Multiflow return inlet to be glued to a Ø50 mm PN10 pipe in concrete pools and with a water outlet through a Ø20 mm hole.
Complies with standards:
EN 16582-1
EN 16713-2
Download DATA SHEET
Multiflow return inlet with grille
MULTIFLOW SYSTEM.
Code | Description |
24414 | Return inlet Multiflow |
The eyeball has been marked with a series of “knock-outs” at 14, 20, and 25 mm, enabling the required flow to be selected at the time of installation.
Recommended max flow 4 m/sec., complies with UNE 13451-1:
Ø 14 mm = 30 m3/h, Ø 20 mm = 4,5 m3/h, Ø 25 mm = 7 m3/h to glue into Ø 50mm 10 bar pipe. Made in white ABS. With grille.
Hidromassage kit – Concrete Pool
Consists of a return inlet and wall conduit equipped.
Code | Description |
31443 | Hydromassage Kit for concrete pools with liner: Length of wall conduit 190 mm Colour White |
31443CL090 | Hydromassage Kit for concrete pools with liner: Length of wall conduit 190 mm Colour Beige |
31443CL129 | Hydromassage Kit for concrete pools with liner: Length of wall conduit 190 mm Colour Light grey |
31443CL144 | Hydromassage Kit for concrete pools with liner: Length of wall conduit 190 mm Colour Anthracite |
32113 | Hydromassage Kit for concrete pools: Length of wall conduit 195 mm Colour White |
32113CL090 | Hydromassage Kit for concrete pools: Length of wall conduit 195 mm Colour Beige |
32113CL129 | Hydromassage Kit for concrete pools: Length of wall conduit 195 mm Colour Light grey |
32113CL144 | Hydromassage Kit for concrete pools: Length of wall conduit 195 mm Colour Anthracite |
32370 | Hydromassage Kit for concrete pools: Length of wall conduit 280 mm Colour White |
32370CL090 | Hydromassage Kit for concrete pools: Length of wall conduit 280 mm Colour Beige |
32370CL129 | Hydromassage Kit for concrete pools: Length of wall conduit 280 mm Colour Light grey |
32370CL144 | Hydromassage Kit for concrete pools: Length of wall conduit 280 mm Colour Anthracite |
32371 | Hydromassage Kit for concrete pools with liner: Length of wall conduit 275 mm Colour White |
32371CL090 | Hydromassage Kit for concrete pools with liner: Length of wall conduit 275 mm Colour Beige |
32371CL129 | Hydromassage Kit for concrete pools with liner: Length of wall conduit 275 mm Colour Light grey |
32371CL144 | Hydromassage Kit for concrete pools with liner: Length of wall conduit 275 mm Colour Anthracite |
Consists of a return inlet and wall conduit equipped with an air inlet and a venturi jet. Two lengths of wall conduit. Ø 50 mm water connection pipe and Ø 20 mm air suction pipe.
Available in white, light grey, beige and anthracite colours.
Download DATA SHEET
Adjustable 3” concrete floor inlet
Made in white ABS.
NORM return inlet for concrete pools
New range of inlets.
Code | Description |
56498 | NORM return inlet for concrete pools |
According to EN 16582-1 and EN 16713-1 , available for public and private pools. Made in white ABS and UV treatment.
Download DATA SHEET
Return nozzle large flow concrete pool
Return inlet for large flow rates.
Code | Description |
41520 | INLET / SUCTION NOZZLE FOR CONCRETE POOL |
Return inlet for large flow rates that can also be used as a suction nozzle. Maximum suction flow rate of 30m3/h for a maximum flow rate speed of 4 m/s. Maximum suction flow rate of 5 m3/h for a maximum flow rate speed of 0.5 m/s. PVC body. Connection for Ø 75 or Ø 90mm pipe. Inlets can be installed into bushing 43590. Grille can be adjusted in any direction.
Complies with standards:
EN 16582-1
EN 16713-2
BOQUILLAS DE IMPULSIÓN ABS PISCINA LINER
Floor return inlet for prefabricated pool
For return. Made in white ABS, with gaskets, flanges, and screws.
Code | Description |
00340 | 2″ external thread Ø 50 internal solvent White |
00340CL090 | Inlet 2” glued thread Ø50 mm Beige |
00340CL129 | Inlet 2” glued thread Ø50 mm Light grey |
00340CL144 | Inlet 2” glued thread Ø50 mm Anthracite |
20139 | Solvent external Ø 63 PN 6, Ø 50 internal solvent |
Adjustable flow. Max. flow. 12 m3/h.
Item available in White, Beige, Light Gray and Anthracite colours.
Complies with standards:
EN 16582-1
EN 16713-2
Download DATA SHEET
Multiflow return inlet Parker model
MULTIFLOW SYSTEM.
Code | Description |
06498 | With self-tapping screws |
The eyeball has been marked with a series of “knock-outs” at 14, 20, and 25, enabling the required flow to be selected at the time of installation.
Recommended max flow 4 m/sec., complies with UNE 13451-1:
Ø 14 mm = 30 m3/h, Ø 20 mm = 4,5 m3/h, Ø 25 mm = 7 m3/h for liner pools, white ABS plastic with gaskets and screws. External thread of 2″, Ø 50 mm solvent internal. Installation with wall conduits 15662 or 15663 is recommended.
Complies with standard:
EN 16582-1
EN 16713-2
BCN03 pool floor return inlet
Adjustable pool floor return inlet for liner pools.
Code | Description |
28230 | PN6, with self-screw |
28231 | PN6, with inserts |
28501 | PN10, stainless steel flange with self-tappers |
28502 | PN10, stainless steel flange with inserts |
Designed to be glued to the inside of PN6 and PN10 piping.
Made of white ABS, with self-tapping screws or with metal inserts. Plastic or stainless-steel flange, depending on the model. Maximum flow rate: 9.5 m3/h.
Complies with standards:
EN 16582-1
EN 16713-2
Hidromassage kit – Prefabricated Pool
Consists of a return inlet and wall conduit equipped.
Code | Description |
32114 | For polyester pools – Length of wall conduit 190 mm Colour White |
32114CL090 | For polyester pools – Length of wall conduit 190 mm Colour Beige |
32114CL129 | For polyester pools – Length of wall conduit 190 mm Colour Light grey |
32114CL144 | For polyester pools – Length of wall conduit 190 mm Colour Anthracite |
32115 | For pools with liner – Length of wall conduit 190 mm Colour White |
32115CL090 | For pools with liner – Length of wall conduit 190 mm Colour Beige |
32115CL129 | For pools with liner – Length of wall conduit 190 mm Colour Light grey |
32115CL144 | For pools with liner – Length of wall conduit 190 mm Colour Anthracite |
32384 | For polyester pools – Length of wall conduit 275 mm Colour White |
32384CL090 | For polyester pools – Length of wall conduit 275 mm Colour Beige |
32384CL129 | For polyester pools – Length of wall conduit 275 mm Colour Light grey |
32384CL144 | For polyester pools – Length of wall conduit 275 mm Colour Anthracite |
32385 | For pools with liner – Length of wall conduit 275 mm Colour White |
32385CL090 | For pools with liner – Length of wall conduit 275 mm Colour Beige |
32385CL129 | For pools with liner – Length of wall conduit 275 mm Colour Light grey |
32385CL144 | For pools with liner – Length of wall conduit 275 mm Colour Anthracite |
Consists of a return inlet and wall conduit equipped with an air inlet and a venturi jet. Two lengths of wall conduit. Ø 50 mm water connection pipe and Ø 20 mm air suction pipe.
Available in white, light Gray, beige and anthracite colours.
Download DATA SHEET
Multiflow return inlet pref pools-liner
These inlets have a smaller exterior diameter.
Code | Description |
32450 | Return inlet for 1½” BSP screw |
32451 | Return inlet for Ø 50 thread |
These inlets have a smaller exterior diameter than previous models to achieve superior adaptation in pools with curved walls.
Complies with standards:
EN 16582-1
EN 16713-2
Download DATA SHEET
3” adjustable floor inleet
Made in white ABS. With gaskets, flanges and screw.
Adjustable liner return inlet
With gaskets, flanges, and screws.
Code | Description |
15864 | Adjustable liner return inlet |
3 adjustable positions. (100%, 65%, & 35%). Max. flow: 13.5 m3/h.
External connection Ø 63 mm.
Complies with standards:
EN 16582-1
EN 16713-2
Download DATA SHEET
Double gasket kit
Kits comprising a double joint and the screws necessary.
Code | Description |
43455-0500 | Double joint kit for inlets, inserts |
Kits comprising a double joint and the screws necessary for the installation of nozzles in steel panel pools. Made of TPE, the kit enables the installation of various accessories in pool basins and protects the panelling from meeting water. Easy to install. Prevents corrosion of the panelling in the moulded area.
We recommend placing the Double gasket kit in pools of sheet metal panels in nozzles 00330; 00332; 17382; 17383 and 56499
Download DIMENSIONS
Multiflow return inlets for panel pools
New inlets especially designed to be installed in panel pools.
Code | Description |
33091 | Return inlet model for panel pools 15 cm |
New inlets especially designed to be installed in panel pools between 10 and 15 cm thick.
The return model propels water from filtering and is installed with a Multiflow eyeball for flow adjustment. The connection is made by gluing a Ø 50 mm pipe.
The design facilitates prior assembly to the panel, in addition to the possibility of using the same wall conduit inlet. Easy to install, watertightness is ensured by placing a washer between the inlet and the liner.
Download DATA SHEET
Return nozzle large flow panel pool
Inlet nozzles for large flows.
Code | Description |
41518 | INLET / SUCTION NOZZLE FOR PANEL POOL |
They can be used as suction nozzle also.
- PVC body, ABS grille, PA flange and AISI 304 screws. Inlet flow rate 30m3/h
- Holes in grilles are not bigger than 8 mm
- Inlet flow rate 30m3/h for a maximum water flow velocity of 4m/s
- Suction flow rate 5m3/h for a maximum water flow velocity of 0.5m/s
- 30º jet inclined at 360 º steerable.
- Ø75 or Ø90 pipe connection
- The nozzle can be installed in the wall conduit 43590.
Complies with Standards:
EN 16582-1
EN 16713-2
Return nozzle large flow prefabricated pool
Inlet nozzles for large flows.
Code | Description |
41521 | INLET / SUCTION NOZZLE FOR PREFABRICATED POOL |
They can be used as suction nozzle also.
- PVC body, ABS grille, PA flange and AISI 304 screws. Inlet flow rate 30m3/h.
- Holes in grilles are not bigger than 8 mm according to EN 13451-1 standard.
- Inlet flow rate 30m3/h for a maximum water flow velocity of 4m/s according to EN 13451-1 standard.
- Suction flow rate 5m3/h for a maximum water flow velocity of 0.5m/s according to EN 13451-1 standard.
- 30º jet inclined at 360 º steerable.
- Ø75 or Ø90 pipe connection.
- The nozzle can be installed in the wall conduit 43590.
- Model 41521 with double gasket.
BCN03 adjustable pool floor return inlet
Pool floor return inlet for liner pools.
Code | Description |
43586 | With plastic flange inserts |
43587 | Plastic self-tapping flanges |
43588 | With stainless steel flange inserts |
43589 | Self-tapping stainless-steel flange |
Thanks to the adjustable feature, its installation in the pool floor is made extremely easy as it can be fitted after the concrete has been laid with wall conduit 43590.
Complies with standards:
EN 16582-1
EN 16713-2
NORM return inlets
Range of inlets suitable for installation.
Code | Description |
17383 | Norm inlet for prefabricated pools, Parker – White |
17383CL090 | NORM inlet for prefabricated pools, Parker – Beige |
17383CL129 | NORM inlet for prefabricated pools, Parker – Light grey |
17383CL144 | Norm inlet for prefabricated pools, Parker – Anthracite grey |
56499 | INLET NORM for prefabricated pool/liner White |
56499CL090 | INLET NORM for prefabricated pool/liner Beige |
56499CL129 | INLET NORM for prefabricated pool/liner Light grey |
56499CL144 | INLET NORM for prefabricated pool/liner Anthracite |
56500 | INLET NORM for prefabricated pool White |
56500CL090 | INLET NORM for prefabricated pool Beige |
56500CL129 | INLET NORM for prefabricated pool Light grey |
56500CL144 | INLET NORM for prefabricated pool Anthracite |
Range of inlets suitable for installation in public and private pools. Manufactured in white ABS with UV treatment.
Item available in White, Beige, Light Gray and Anthracite colours.
Download DATA SHEET
Concrete floor inlet
Return / Suction. Adjustable flow.
Code | Description |
00303 | 2″ external thread, Ø 50 mm solvent internal White |
00303CL090 | INLET 2’’ GLUED THREAD (Ø50mm) Beige |
00303CL129 | INLET 2’’ GLUED THREAD (Ø50mm) Light Gray |
00303CL144 | INLET 2’’ GLUED THREAD (Ø50mm) Anthracite |
20140 | to glue onto Ø 63 PN 6, Ø 50 mm solvent internal |
Made in white ABS, screw in S.S. Max. flow: 12000 l/h.
Item available in White, Beige, Light Gray and Anthracite colours.
Complies with standards:
EN 16582-1
EN 16713-2
Download DATA SHEET
Multiflow return inlet threated for liner
MULTIFLOW SYSTEM.
Code | Description |
00330 | Liner return inlet |
00330CL090 | INLETMULTIFLOW WITH 2’’ GLUED THREAD (Ø50 mm) Beige |
00330CL129 | INLETMULTIFLOW WITH 2’’ GLUED THREAD (Ø50 mm) Light gray |
00330CL144 | INLETMULTIFLOW WITH 2’’ GLUED THREAD (Ø50 mm) Anthracite |
The eyeball has been marked with a series of “knock-outs” at 14, 20, and 25, enabling the required flow to be selected at the time of installation.
Recommended max flow 4 m/sec., complies with UNE 13451-1:
Ø 14 mm = 30 m3/h, Ø 20 mm = 4,5 m3/h, Ø 25 mm = 7 m3/h for liner pools, white ABS plastic with gaskets and screws. External thread of 2″, Ø 50 mm solvent internal. Installation with wall conduits 15662 or 15663 is recommended.
Item available in White, Beige, Light Gray and Anthracite colours.
Complies with standard:
EN 16582-1
EN 16713-2
Download DATA SHEET
STAINLESS STEELS RETURN INLET FOR CONCRETE POOLS
Adjustable concrete return inlet
Chrome on brass, grille in S.S. AISI-304L.
Code | Description |
00312 | Max. flow: 21000 l/h internal thread 2″ |
00313 | Max. flow: 40000 l/h internal thread 3″ |
Complies with standards:
EN 16582-1
EN 16713-2
EN 13451-1-3
Download DATA SHEET
Adjustable return inlet
2″ external thread. Made in S.S. AISI-316L.
Code | Description |
15839 | Adjustable return inlet |
Allows installation in both concrete and prefabricated pools. Water flow may be adjusted by the central screw. Max. recommended flow: 14m3/h
Complies with standards:
EN 16582-1
EN 16713-2
EN 13451-1-3
Download DATA SHEET
Return inlet
External thread 1 1/2″. Made in S.S. AISI-316L.
Code | Description |
16325 | Length 50 mm |
16326 | Length 70 mm |
32994 | Length 35 mm |
Recommended max. flow. Complies with EN 16582-1 and EN 16713-2: 4500 l/h. Ball Ø 20 mm.
Return inlet with Ø 25 mm ball
1 1/2″ external thread. Manufactured in AISI-316L stainless steel.
Code | Description |
69874 | Length 35 mm |
69875 | Length 50 mm |
69876 | Length 70 mm |
Maximum recommended flow rate according to EN 13451-3 standard: 7 m3/h. Ø 25 mm ball.
Complies with standards:
EN 16582-1
EN 16713-2
EN 13451-1-3
Download DATA SHEET
STAINLESS STEELS RETURN INLET FOR LINER POOLS
Liner return inlet
External thread 11/2″. Made in S.S. AISI-316L.
Code | Description |
16327 | Liner return inlet |
Ø 20 mm eyeball. Complete with gaskets & screws.
Recommended flow: 4.5 m3/h
Complies with standards:
EN 16582-1
EN 16713-2
Download DATA SHEET
Panel pool adapter
1 1/2″ external thread. Made in S.S. AISI-316L.
Code | Description |
26171 | Panel pool adapter |
Allows installation in both concrete and prefabricated pools. Water flow may be adjusted by the central screw. To be used with 16331.
Complies with standards:
EN 16582-1
EN 16713-2
EN 13451-1-3
Return inlet for liner pool
Made of AISI-316L stainless steel.
Code | Description |
16331 | Liner return inlet |
Fits to 00344 and 00345 wall conduits and adapts to wall conduit 26171. Comes with gaskets and screws. Ø 20 mm eyeball. Eyeball fitted using screws. Recommended flow rate: 4.5 m3/h.
Complies with standards:
EN 16582-1
EN 16713-2
Return nozzle for liner pools Ø 25 mm eyeball.
Outer 11/2″ thread. Made of AISI-316L stainless steel.
Code | Description |
69877 | Return nozzle for liner pools |
Ø 25 mm eyeball. Comes with gaskets and screws. Recommended flow rate: 7 m3/h.
Complies with standards:
EN 16582-1
EN 16713-2
EN 13451-1-3
Download DATA SHEET
Wall conduit return nozzle for liner pools
Made of AISI-316L stainless steel.
Code | Description |
69878 | Wall conduits return nozzle for liner pools |
Fits to 00344 and 00345 wall conduits and adapts to wall conduit 26171. Comes with gaskets and screws. Ø 25 mm eyeball. Eyeball fitted using screws. Recommended flow rate: 7 m3/h.
Complies with standards:
EN 16582-1
EN 16713-2
EN 13451-1-3
Download PARTS BREAKDOWN
ABS SUCTION INLET FOR CONCRETE POOLS
Suction nozzle Ø 63 and Ø 50
To be glued to Ø 63 mm and Ø 50 mm piping.
Code | Description |
00300 | Standard inlet- White |
00300CL090 | Standard inlet – Beige |
00300CL129 | Standard inlet – Light grey |
00300CL144 | Standard inlet – Anthracite Gray |
Maximum pressure: 6 bar. Made of white ABS. 11/2” thread.
Recommended for installation with wall conduits: code numbers 15661 and 15660.
Complies with standards:
EN 16582-1
EN 16713-2
Download DATA SHEET
Concrete suction nozzle 2” male thread
Outer 2″ thread, Ø 50 mm inner wall.
Overflow channel drainage point
To be glued to external Ø 63 mm.
Concrete suction nozzle to glue to Ø50
To glue inside Ø 50 mm 10 bar pipes.
Code | Description |
24415 | Concrete vacuum point |
Made in white ABS. Plug thread 1 1/2”. Recommended to be installed with wall conduits 15658 & 15659. End connection 07958 and push fit connection 01393.
Download DATA SHEET
ABS SUCTION INLET FOR LINER POOLS
Suction nozzle for liner pool
Made in ABS, with plug, gaskets, & screws.
Code | Description |
00332 | Suction nozzle for liner pool. 2” external thread, Ø 50 mm solvent internal |
Code 00332 is recommended to be installed with wall conduit 15663.
Item available in White, Beige, Light Gray and Anthracite colours.
Complies with Standards:
EN 16582-1
EN 16713-2
Download DATA SHEET
Suction nozzle for panel pools
New inlets especially designed to be installed in panel pools.
Code | Description |
33092 | Suction inlet model for panel pools 15 cm |
New inlets especially designed to be installed in panel pools between 10 and 15 cm thick.
The suction model can be used to connect bottom cleaners with a 1½ inches BSP thread. The connection is made by gluing a Ø 50 mm pipe.
The design facilitates prior assembly to the panel, in addition to the possibility of using the same wall conduit inlet. Easy to install, watertightness is ensured by placing a washer between the inlet and the liner.
Complies with Standards:
EN 16582-1
EN 16713-2
Suction nozzle for overflow with liner
Suction nozzle for overflow with liner.
Code | Description |
41519 | SUCTION NOZZLE FOR OVERFLOW WITH LINER |
- PVC body, PA flange and Stainless-Steel screw.
- Suction flow rate 7m3/h for a maximum water flow velocity of 0.5m/s
- Internal connection with Ø 75 mm tube or outside with Ø 90 mm tube. + connection link
- Double gasket
Complies with Standards:
EN 16582-1
EN 16713-2
Return nozzle for liner pools
Comes with gaskets, flanges and screws.
Code | Description |
17382 | Suction nozzle for liner pool. 2” external thread, Ø 50 mm solvent internal |
17382CL090 | Suction nozzle for liner pool. 2” external thread, Ø 50 mm solvent internal Beige |
17382CL129 | Suction nozzle for liner pool. 2” external thread, Ø 50 mm solvent internal Light Grey |
17382CL144 | Suction nozzle for liner pool. 2” external thread, Ø 50 mm solvent internal Anthracite |
Connections: outer 2″ thread and Ø 50 mm inner.
Complies with Standards:
EN 16582-1
EN 16713-2
Download DATA SHEET
STAINLESS STEELS SUCTION INLET FOR CONCRETE POOLS
Suction point with sliding cover
Chrome on brass with S.S. AISI-304L cover.
Code | Description |
00315 | Suction point with sliding cover |
Push fit. 2″ Internal thread
(01392 coupling bushing is required for hose).
Complies with standards:
EN 16582-1
EN 16713-2
EN 13451-1-3
Suction point with threaded cover
Suction point with threaded cover.
Code | Description |
00317 | Suction point with threaded cover |
Screws into 2” inner thread (01395 coupling is required for hose).
Suction point
Outer 11/2″ thread. Made of AISI-316L stainless steel.
Code | Description |
16328 | Length 50 mm |
21644 | Length 50 mm with lid |
An 05684-end connector is required.
Complies with standards:
EN 16582-1
EN 16713-2
EN 13451-1-3
STAINLESS STEELS SUCTION INLET FOR LINER POOLS
Suction nozzle for liner pool
Made in S.S. AISI-316L, with gaskets, flange and screws.
Code | Description |
16330 | Liner suction inlet |
With 11/2”; BSP male thread.
Complies with standards:
EN 16582-1
EN 16713-2
EN 13451-1-3
Download DATA SHEET
DRAIN NOZZLES – POLYESTER POOLS
Drain nozzles – Polyester pools
Specially designed for polyester pools.
Code | Description |
74121 | Drain nozzle – Colour White |
74121CL090 | Drain nozzle – Colour Beige |
74121CL129 | Drain nozzle – Colour Light grey |
74121CL144 | Drain nozzle – Colour Anthracite |
Drain nozzle that should be installed in the wall of the pool in the deepest area of the pool.
Installation with 2″ thread, gasket, and nut. Made of ABS.
Download DATA SHEET
RETURN INLETS POLYESTER POOLS
Boquilla de impulsión Multiflow para piscina de poliéster
MULTIFLOW SYSTEM
Code | Description |
00334 | 2” male thread. Inside solvent weld Ø 50 mm – Colour White |
00334CL090 | 2” male thread. Inside solvent weld Ø 50 mm – Colour Beige |
00334CL129 | 2” male thread. Inside solvent weld Ø 50 mm – Colour Light grey |
00334CL144 | 2” male thread. Inside solvent weld Ø 50 mm – Colour Anthracite |
06481 | 2” male thread and 1 1/2” female thread |
53863 | 2” male thread. Inside solvent weld Ø 50 mm – Emb. Ø 90 – Colour White |
The eyeball has been marked with a series of “knock-outs” at 14, 20, and 25, enabling the required flow to be selected at the time of installation.
Recommended max flow 4 m/sec., complies with UNE 13451-1:
Ø 14 mm = 30 m3/h, Ø 20 mm = 4,5 m3/h, Ø 25 mm = 7 m3/h.
Code 00334: 2″ external thread. Ø 50 mm. solvent internal. Made in white ABS.
Code 06481: 2″ external thread. 11/2″ internal thread. In white ABS with gaskets. Slots < 8 mm complies with UNE 13451-1 standard.
Complies with standards:
EN 16582-1
EN 16713-2
Download DATA SHEET
SUCTION INLETS POLYESTER POOLS
Suction nozzle for polyester pool
00336: 2″ external thread, Ø 50 mm solvent internal.
Code | Description |
00336 | 2” external thread, Ø 50 mm solvent internal |
00336CL090 | 2” external thread, Ø 50 mm solvent internal Beige |
00336CL129 | 2” external thread, Ø 50 mm solvent internal Light Grey |
00336CL144 | 2” external thread, Ø 50 mm solvent internal Anthracite grey |
06484 | 2” external thread, internal thread 1 1/2” |
11582 | NPT outlet |
53862 | 2” external thread, Ø 50 mm solvent internal |
For polyester pools, made in ABS, with plug thread 1 1/2″, gaskets, & screws.
06484: 2″ external thread, internal thread 1 1/2″. Made in ABS.
Complies with Standards:
EN 16582-1
Download DATA SHEET
